10FT Expandable Folding House
Quick installation, expandable design, can be set up in a short time
Easy transportation, compact folding size for standard container shipping
Strong structure, high-strength steel frame with excellent stability
Good insulation, heat, wind, and water resistant wall panels
Reusable and movable, can be relocated multiple times without damage
Flexible layout, customizable interior design based on needs
Cost-effective, saves construction time and labor costs
Wide application, suitable for residential, office, and temporary use
Product Details
The 10ft expandable folding house is a compact, prefabricated modular housing unit designed for fast deployment and flexible living space expansion. It adopts a foldable structure that can be transported in a standard container size and quickly expanded on-site, significantly reducing installation time and labor costs.
Built with a high-strength steel frame and insulated wall panels, the house offers excellent durability, thermal insulation, waterproofing, and wind resistance. Its modern design includes doors, windows, and optional interior layouts, making it suitable for both temporary and semi-permanent use.
Product Specifications
| Product Specifications – 10-foot twin wings | |||
|---|---|---|---|
| Product Model | 10-foot twin wings | Number of guests | 2-4 people |
| Expansion size | L2950 * W6300 * H2480 | Electric power | 12KW |
| Internal dimensions | L2690 * W6140 * H2240 | Shipping Weight | About 2.3 tons |
| Folded size | L2950 * W2200 * H2480 | Land area | 18.5 m² |
| Framework Structure & Component Details | |||
| Main frame (fully galvanized) |
top beam | 80 * 80 * 2.5mm square tube | |
| head piece | Bending part 2.0mm | ||
| bottom main beam | 80 * 140 * 2.5mm square tube | ||
| Bottom crossbeam | Bending part 2.0mm | ||
| column head | Bending part 2.0mm (6mm hanger inner lining) | ||
| Side frame (fully galvanized) |
top frame | 40 * 80 * 1.5mm P-shaped pipe | |
| 40 * 80 * 1.5mm square tube | |||
| 2.0mm bent part | |||
| Bottom frame | 60 * 80 * 2.0mm square tube | ||
| 80 * 80 * 1.5mm square tube | |||
| Folding hinge | 130mm galvanized hinge | ||
| overall frame protective coating | flame plating | electrostatic spraying | |
| box top | External top | 0.35mm corrugated board | |
| internal roof | 50mm EPS Sandwich Panel | ||
| Internal ceiling panel | 50mm EPS Sandwich Panel | ||
| wallboard | external wall panel | 75mm EPS Sandwich Panel | |
| floor | Central base | Fireproof magnesia board floor, 18mm thick | |
| lateral margin | Fireproof magnesia board floor, 18mm thick | ||
| floor | PVC flooring 2.0mm / Stone-plastic flooring 4.0 | ||
| doors and windows | windows | 930mm * 930mm | |
| Entrance door | Industry standard | ||
| Electrical system | Circuit Breaker System | 1 leakage circuit breaker / 4 circuit breakers | |
| lamp | LED round ceiling light | ||
| Socket | On demand | ||
| Light switch | Double switch, single button | ||
| Wiring | Incoming line 6², air conditioner socket 4², regular socket 2.5², lighting 1.5² | ||
